Shaking table

Wet Minerals Shaking Table Separation is one of the important dressing equipment depending on the gravity. It is widely used in to classify the granularity 2-0.02 millimeters ore and ore slime of tungsen, tin, niobium, manganese, chromium, titanium, lead , zinc, gold, iron(rediron, brown iron) and so on metallic minerals. It is easy to be operated and can prduce high grade concentrated ore, secondary concentrated ore, middlings and gangue, etc at the same time, it is widely used to separate tungsten, stanum, niobium,gold, other rare metal and nobel metal ores, it can also be used to separate iron, manganese minerals, coal and so on.

Working Principle

The working principle of Shaking Table is to use the combined action of the specific gravity difference of sorted minerals, alternating movement of bed surface, and transverse oblique water flow and riffle (or notch groove),to allow loose layering of ores on the bed surface and fan-shaped zoning. Then different products can be produced.

Advantages:

High recovery ratio

High concentration ratio

Easy installation

Simple operation

Deck constructed of fiber glass

Long working life

Adjustable stroke length and speed
