Spiral sand washing machine

Spiral sand washing machine is divided into two types: single spiral sand washing machine and double spiral sand washing machine.
It is mainly used for washing, grading and removing impurities in highway, hydropower, construction and other industries, as well as fine-grained and coarse-grained materials washing and other operations .
It has low power consumption and high washing degree. The good sealing structure, fully enclosed transmission device and adjustable weir plate ensure the characteristics of high efficiency, durability, good cleaning and dehydration effect, and the stability of fine-grained products.

Spiral sand washing machine
Spiral sand washing machine
Spiral sand washing machine
Spiral sand washing machine
Spiral sand washing machine
Spiral sand washing machine

Product Description

The spiral sand washing machine is a kind of sand washing machine. It mainly stirs the sand and gravel material through the screw device in the equipment, so that the soil and water in the sand and gravel material are mixed and discharged from the outflow port on the equipment, while the sand and gravel material is in Under the action of the screw device, it is gradually screened and discharged from the discharge port at the top, thereby realizing the cleaning and screening effect of the gravel material.

The spiral sand washing machine is suitable for washing, grading and impurity removal in metallurgy, building materials, hydropower and other industries, and is used for washing fine and coarse-grained materials. It is suitable for construction sand and road construction sand and gravel. The spiral sand and stone washing machine has low power consumption and high washing degree. Good sealing structure, fully enclosed transmission device, and adjustable weir plate ensure that the product has the characteristics of high efficiency, durability, good cleaning and dehydration effect, and the stability of fine-grained products.

Henan Hengtailong Machinery Co., Ltd. Henan Hengtailong Machinery Co., Ltd.

Feature:

  • 1Simple structure and stable operationt
  • 2The bearing is separated from water and materials to avoid damage caused by premature contamination and rusting of the machine.
  • 3Suitable for various working environments
  • 4The loss of washed materials is low, and the efficiency of selective washing is high, which can fully meet the requirements of high-grade materials.
  • 5Long service life, almost no wearing parts.
  • 6Maintenance is required in rare cases, so the cost can be greatly reduced.



Technical Parameters

 Model

 Spiral Dia.(mm)

 Rotate Speed
(r/min)

input Size
(mm)

Water Consumption
(T/h)

Capacity
(T/h)

Power (Kw)

Weight (Kg)

LXS -508

Φ508

38

≤10

6-40

20-30

5.5

2670

LXS -610

Φ610

32

≤10

6-50

30-40

7.5

3800

LXS -762

Φ762

26

≤10

9-63

75

11

4020

LXS -914

Φ914

20

≤10

10-80

100

11

6500

LXS-1118

Φ1118

18

≤10

27-168

175

15

8690

LXS -1500

Φ1500

13

≤10

27-180

220

18.5

16580

2LXS -762

Φ762

26

≤10

136-182

145

11×2

8140

2LXS -914

Φ914

21

≤10

120-150

200

11×2

13500

2LXS-1118

Φ1118

17

≤10

200-250

300

15×2

19800
