jig machine separator

[Feed size]: 5-30mm
[Production capacity]:  2-15t/h
[Scope of application]:  Mining, Metallurgical,chemical, building materials
[Product introduction]:Jigger machine is widely used in manganese ore, Lead-zinc mine, lapis lazuli, barite ore, fluorite, pyrite, limonite, hematite, mercury and other minerals re-election.

Send E-mail Inquire Now
jig machine separator
jig machine separator
jig machine separator
jig machine separator
jig machine separator
jig machine separator

Product Description

Jigger machine separation belongs to deep groove sorting operation in ore dressing work. It adopts water as beneficiation medium, separates the minerals by use of gravity differences between the mineral ore and gangue. AM30 jig machine is applied to the separation operation. It has a good effect on the separate of big size raw ore and the recovery of large non-ferrous metal smelting slag.

Henan Hengtailong Machinery Co., Ltd.

Working Principle:

Jigger machine beneficiation is one way of gravity beneficiation. It belongs to deep trough separation operations, use water as processing media, it depends on the difference of specific gravity between the mine to be select and gangue to separate mine, They are mostly in septum type, the stroke and time of stroke is adjustable depend on different specific gravity of mine, it’s widely used to select Tungsten, tin, gold, red iron, brown iron, manganese, titanium, antimony, lead, tantalum, niobium and other metal.

Henan Hengtailong Machinery Co., Ltd.

Advantages:

1. Large processing capacity, wide sorting size range
2. High enrichment ratio and high recovery rate
3. Easy installation, easy operation, easy maintenance
4. Adjustable speed motor
5. Low water consumption
Henan Hengtailong Machinery Co., Ltd.



Technical Parameters

Model

Jig Room

Stroke Coefficient

Septum

Input Size

(mm)

Capacity

(t/h)

Water Consumption

(t/h)

Power

(kw)

Weight

(kg)



Area

(m2)

Raw

Room

Total Area

(m2)



Stroke

(mm)

Times

(mm)











LTP-34/2

0.135

1

2

0.27

0.58

0-25

320-420

12

2-6

4-10

1.1

800

LTA-1010/2

1.0

1

2

2.0

0.5

0-25

250-350

5

5-15

10-20

2.2

2890

LTC-69/2

0.54

1

2

1.08

0.55

0-50

220-350

8

6-9

40-60

1.5

1420

2LTC-366/8T

0.2-0.34

2

8

2.16

0.68-0.41

0-50

120-300

5

3-6

20-40

1.1x2

3570

2LTC-6109/8T

0.58-0.86

2

8

5.76

0.52-0.35

0-50

120-300

5

10-20

80-120

2.2x2

4650

AM-30

0.644

2

2

2.574

0.47

0-50

130

30

10-15

100-150

3

2400
